Actual part may differ slightly from image shown.

1/2" PVC TBH Series Ball Valve, SOC/THD Ends, FPM Seals, Z Ball

The Hayward TBH Series 1/2" PVC Z-Ball True Union Ball Valve with FPM seals is specifically engineered for sodium hypochlorite (bleach) and gas-generating chemical service. The Z-Ball features a drilled vent hole that prevents trapped gas pressure from building behind the ball — a critical safety requirement in chlorine and hypochlorite dosing systems. FPM seals for maximum chemical resistance. System2™ Sealing Technology for reliable shutoff. IMPORTANT: Uni-directional — follow flow direction arrow on body. ISO 5211 mounting pad, integral lock-out plate, reversible PTFE seats, true union socket/threaded end connectors. 250 PSI / PN16 at 70°F. NSF/ANSI 61 & 372.

Additional Info

Brand: Hayward Flow Control
Series: TBH Series With "Z-Ball" True Union Ball Valves
Seal Material: FPM (FKM/Viton)
Size in Inches: 1/2 Inch
Connection Type: Socket/Threaded True Union
Material: PVC
PSI: 250 PSI
Application: Sodium Hypochlorite / Chlorine Gas
Temp. Range: 140°F

PVC Fittings Online  |  SKU: TBH1050ASTV0Z00

1/2" PVC TBH Series Ball Valve, SOC/THD Ends, FPM Seals, Z Ball

Hayward 1/2" PVC TBH Series True Union Ball Valve with Z-Ball and FPM seals — engineered for sodium hypochlorite and chlorine gas service. Vented Z-Ball prevents trapped gas pressure buildup. Rated 250 PSI, uni-directional. NSF/ANSI 61 & 372 certified.
$73.33
Shipping calculated at checkout.

This is a Furniture Grade item - NOT MEANT FOR PLUMBING.
Hayward 1/2" PVC TBH Series True Union Ball Valve with Z-Ball and FPM seals — engineered for sodium hypochlorite and chlorine gas service. Vented Z-Ball prevents trapped gas pressure buildup. Rated 250 PSI, uni-directional. NSF/ANSI 61 & 372 certified.

Bulk orders? Get a quote over $1000

Description

The Hayward TBH Series 1/2" PVC Z-Ball True Union Ball Valve with FPM seals is specifically engineered for sodium hypochlorite (bleach) and gas-generating chemical service. The Z-Ball features a drilled vent hole that prevents trapped gas pressure from building behind the ball — a critical safety requirement in chlorine and hypochlorite dosing systems. FPM seals for maximum chemical resistance. System2™ Sealing Technology for reliable shutoff. IMPORTANT: Uni-directional — follow flow direction arrow on body. ISO 5211 mounting pad, integral lock-out plate, reversible PTFE seats, true union socket/threaded end connectors. 250 PSI / PN16 at 70°F. NSF/ANSI 61 & 372.

Additional Info
Brand: Hayward Flow Control
Series: TBH Series With "Z-Ball" True Union Ball Valves
Seal Material: FPM (FKM/Viton)
Size in Inches: 1/2 Inch
Connection Type: Socket/Threaded True Union
Material: PVC
PSI: 250 PSI
Application: Sodium Hypochlorite / Chlorine Gas
Temp. Range: 140°F
