PVC Fittings Online | SKU: AM1648P30

AM1648P30 16x14x8 NEMA 4X Fiberglass Enclosure w/ Lift-Off Screw Cover 30 PB Cutouts 30.5MM

Name: AM1648P30 16x14x8 NEMA 4X Fiberglass Enclosure w/ Lift-Off Screw Cover 30 PB Cutouts 30.5MM
Brand: PVC Fittings Online
SKU: AM1648P30
Price: 252.07 USD
Availability: InStock

AM Series Pushbutton Enclosure with Multi-Hole Hinged Screw Cover - Part: AM1648P30

Allied Moulded enclosures have a 4-6 week lead time.

$252.07

Shipping calculated at checkout.

This is a Furniture Grade item - NOT MEANT FOR PLUMBING.

Actual part may differ slightly from image shown.

Description

Easier to use and to modify all Allied's electrical enclosures are made for indoor and outdoor applications. Created to withstand various environments and weather conditions. This product has a lift-off 4-screw solid cover.

Additional Info

Related Documents: Not Available

Part Number: AM1648P30

Box Dimensions: 16.27" (H), 14.4" (W), 8" (D)

Cover Type: Pushbutton

Cover/Base Material: ULTRAGUARD Fiberglass reinforced polyester - compression molded SMC box and Cover

Latch Type: Screw Cover

Gasket Material: Closed cell neoprene cord gasket

Back Panel Insert Material: Brass

Mounting Feet Material: Stainless Steel

Weight (lbs.): 13

UPC Code: 85339916581

Standards: UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175CSA-C22.2 No. 14 and CSA C22.2 No. 94 Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. 89590

Compliance: EN / IEC 60204-1 and 60529 Type IP66, RoHS directive

Optional Accessories: Hole Plugs, Pole Mount Kit, Back Panels

Fastener Material: 300 Series stainless steel external hardware (hinges, latches and fasteners)
