24v Thermo-Electric Actuator w/ Low Power Consumption and Auxiliary Micro Switch (656414)

24 V AC/DC with microswitch. Thermo-electric actuator for electric control of radiator valves. Fits valves 220, 221, 338 and 339 series. Low current draw. Power supply: 24 V AC/DC. Initial current draw: ? 250 mA. Power consumption: 3 W, 6 VA. 31.5" wire lead connection. We carry this and many other sizes. Don't see the part you need? Give us a call today!

Protection Class: NEMA 3 (IP54)

Power Supply: 24V AC/DC

Initial Current Draw: ≤ 250mA

Power consumption: Holding: 3 W Inrush: 6 VA

Rating of micro-switch contacts: 5A (24V)

SKU:  656414
